AG-P100 · Pole-Mounted Smart Security Node
A fully self-contained, AI-powered security node engineered to mount on any existing pole, wall or structure. Multi-sensor 4K video, thermal imaging, PTZ tracking, fisheye anti-blind-spot coverage, active audio talk-down and a deterrence strobe, all in one hardened enclosure. Every AutoGuard Pole is backed by Aventyr's ULC-certified 24/7 monitoring centre for live response, verified alarms and dispatch-grade evidence.
4K
Multi-sensor video
48 hr
UPS battery backup
3 yr
On-device video retention
Key Features
Mounts to What You Already Have
Attaches to any existing pole, wall or column. No trenching, no new infrastructure, no site disruption. Typical install runs under two hours.
Thermal in Zero Light
Military-grade thermal optics detect heat signatures through smoke, dust and total darkness, where conventional cameras see nothing.
PTZ Plus Fisheye
Dual 4K cameras with PTZ for active tracking and zoom, plus a fisheye lens that removes the blind spot directly below the unit.
Talk-Down and Strobe
An integrated speaker horn lets a monitoring operator speak to an intruder in real time, backed by a high-intensity strobe that triggers on detection.
48-Hour Battery Backup
UL-Listed power supply with 48 hours of lithium UPS. AC-fail, low-battery, charger-fail and DC-fail conditions are individually supervised.
Unlimited 5G, Site Wi-Fi
Independent 5G cellular with multi-carrier failover, plus onboard Wi-Fi broadcast for site personnel and devices.
Specifications
Cameras and AI Analytics
Primary video
Dual 4K multi-sensor cameras
PTZ
Active tracking and optical zoom
Thermal
Military-grade optics for zero-light detection
Fisheye
Eliminates the blind spot directly below the unit
Edge AI
Person and vehicle discrimination, no false alarms on animals or foliage
ALPR
Licence plate capture and watchlist matching
Facial recognition
Watchlist matching with authorized-personnel exclusion
Behavioural alerts
Loitering, line-crossing and perimeter breach
Connectivity and Power
Cellular
Independent 5G with multi-carrier failover
Site Wi-Fi
Onboard broadcast for personnel and devices
Input power
110 V AC, with solar and PoE options
Battery
UL-Listed supply, 48-hour lithium UPS
Supervision
AC-fail, low-battery, charger-fail and DC-fail
Protection
Surge protection and GPS position monitoring
Monitoring link
Encrypted to Aventyr ULC-certified monitoring centre
Enclosure and Deployment
Enclosure
IP66-rated hardened aluminum
Tamper detection
Cover and mounting bracket
Mounting
Universal pole, wall and column hardware
Install time
Under two hours, zero trenching
Video retention
30 / 60 / 90 / 120 / 365 days, up to 3 years on-device
Operating range
−40 °C to +50 °C, heater kit optional for sub-zero
Arming
Auto-arm failsafe on a pre-determined schedule
Response
Live voice-down and verified-alarm guard dispatch
Who Runs This Already
UL 827 Listed
ULC-Certified Monitoring
Serving All of North America
1-833-927-0192
Ready to deploy on your site?
All AutoGuard units are lease-to-own. Aventyr handles installation, calibration and service.
